آموزش راه‌اندازی ماژول شیفت رجیستر 8 بیتی SN74HC164D با آردوینو

/*
Create on January 09, 2024
Create by MohammedDamirchi
<blockquote class="wp-embedded-content" data-secret="Cnmyr7nbY1"><a href="https://electropeak.com/learn/">Home</a></blockquote><iframe loading="lazy" class="wp-embedded-content" sandbox="allow-scripts" security="restricted" style="position: absolute; clip: rect(1px, 1px, 1px, 1px);" title="&#8220;Home&#8221; &#8212; Electropeak" src="about:blank" data-secret="Cnmyr7nbY1" width="600" height="338" frameborder="0" marginwidth="0" marginheight="0" scrolling="no" data-rocket-lazyload="fitvidscompatible" data-lazy-src="https://electropeak.com/learn/embed/#?secret=UYTChE7bpm#?secret=Cnmyr7nbY1"></iframe><noscript><iframe class="wp-embedded-content" sandbox="allow-scripts" security="restricted" style="position: absolute; clip: rect(1px, 1px, 1px, 1px);" title="&#8220;Home&#8221; &#8212; Electropeak" src="https://electropeak.com/learn/embed/#?secret=UYTChE7bpm#?secret=Cnmyr7nbY1" data-secret="Cnmyr7nbY1" width="600" height="338" frameborder="0" marginwidth="0" marginheight="0" scrolling="no"></iframe></noscript>
*/

#include <Arduino.h>
#include <SN74HC164D.h>

SN74HC164D xx164;

void setup()
{
  Serial.begin(9600);
  Serial.println("test");
  xx164.begin(7, 6, 5, 4);
  xx164.rainbow();
}

void loop()
{
  if (Serial.available())
    xx164.write(Serial.read() - 48, MSBFIRST);
}
