این کالا از چرخه تجدید موجودی کافه ربات حذف شده و فقط بصورت پیش سفارش ارائه میشود.
The Timer Module TRM01 is a versatile delay timer relay that supports multiple delay functions and adjustable timing. With a working voltage range of DC 5V, 12V, and 24V, it is suitable for a variety of applications requiring precise time control. This module allows easy selection of delay functions via button inputs and adjustment of delay time using a potentiometer.
Specifications of Timer Module TRM01
-
Working Voltage: DC 5V, 12V, 24V (Optional)
-
Working Current: <1mA (relay not operating)
-
Load Capacity:
-
Normally Open Port: DC 0-30V/10A, AC 0-250V/10A
-
Normally Closed Port: DC 0-28V/10A, AC 0-125V/10A
-
-
Delay Time Range: 0.1 to 120 seconds (adjustable via potentiometer)
-
Functions:
-
F1: Power-on delay pull-in
-
F2: Power-on delay disconnect
-
F3: Self-locking relay mode
-
F4: Level trigger mode
-
-
Working Temperature: -20°C to 60°C (limit: -30°C to 70°C)
-
Dimensions: ---
How to Use of Timer Module TRM01
-
Select Function: Use the button to select one of the four available functions (F1, F2, F3, F4).
-
Adjust Delay Time: Rotate the potentiometer to set the desired delay time within the range of 0.1 to 120 seconds.
-
Signal Input: Apply a high-level pulse signal to the X1 interface for mode-specific operations.
-
Connect Load: Attach the load to the normally open or normally closed port based on the desired operation.
-
Power the Module: Supply the appropriate working voltage (DC 5V, 12V, or 24V).
Datasheet of Timer Module TRM01
Datasheet: Not available
